10.1inch Resistive Touch Screen LCD, 1024×600 resolution, Designed for Raspberry Pi - Waveshare

Waveshare

3 reviews Write a Review
SKU:
061-11870
Manufacturer Part Number:
11870
₹6,810.96 inc. GST
₹5,772.00 ex. GST
10.1inch Resistive Touch Screen LCD, 1024×600 resolution, Designed for Raspberry Pi - Waveshare
The 10.1-inch resistive touch screen LCD with a resolution of 1024x600 is specifically designed for use with Raspberry Pi. It offers touch-sensitive interaction, making it ideal for various projects requiring visual display and user input. View full description
₹6,810.96 inc. GST
₹5,772.00 ex. GST
13 people looking at this.

Description

This 1024x600 HDMI Display with Resistive Touch Control is designed specifically for use with the Raspberry Pi. It features a high resolution of 1024x600 and resistive touch control. The display is compatible with all revisions of the Raspberry Pi except for the Pi 1 Model B or Pi Zero, which require an HDMI cable. Drivers are provided, and it works with your own Raspbian/Ubuntu directly. The display can also work as a computer monitor, but in this case, the touch panel is unavailable and an HDMI cable is required.
The display has an HDMI interface for displaying, and no I/Os are required (although the touch panel still needs I/Os). The backlight can be turned off to lower power consumption. The display is designed to be easy to set up and use, with no additional software or hardware required.

Features:
  • 1024x600 high resolution
  • Resistive touch control
  • Compatible and Direct-connect with any revision of Raspberry Pi (except the Pi 1 model B or Pi Zero, which requires an HDMI cable)
  • Drivers provided (works with your own Raspbian/Ubuntu directly)
  • Also works as a computer monitor, in this case, touch panel is unavailable and HDMI cable is required
  • HDMI interface for displaying, no I/Os required (however, the touch panel still needs I/Os)
  • Backlight can be turned off to lower power consumption
Package Content:
  • 10.1inch HDMI LCD x 1
  • HDMI connector x 1
  • Touch pen x 1
  • RPi screws pack (4pcs) x 1
Development Resources:




Technical Specifications

Brand:
Waveshare
Display Size:
10.1 inch
Resolution:
1024x600
Interface:
HDMI
Display Panel:
IPS
View Angle:
170 degree
Touch Type:
Resistive
Touch Port:
SPI
Touchened Glass Panel:
No
Fully Laminated:
No
Speaker:
No
Signal Output:
No
Device Support - PI:
Yes
Device Support - Jetson Nano:
No
Device Support - PC:
Display Only
