Clean Room Monitor with Temperature, Relative Humidity and Differential Pressure Sensor for Cold Storage

No reviews yet Write a Review
Evelta SKU:
187-CRM-313-I
Manufacturer Part Number:
CRM-313-I
₹18,585.00 inc. GST
₹15,750.00 ex. GST
Request a quote for higher quantities

Description

The Clean Room Temperature, Relative Humidity, Differential Pressure Monitor – (CRM-313-I) is the latest upgraded, flush mounted monitoring equipment, which is used during and after mapping and validation processes for analyzing and continuous monitoring at research labs, cold storage warehouses in industries like Pharma manufacturing & packaging, Animal Housing, and Hospitals & Meteorological industries.

Features
  • 7 Segments L.E.D. display Indication for Temperature, Humidity & Differential
  • Pressure at a time
  • Integrated Temperature and Humidity sensor connection facility.
  • Independent Programmable Alarm for Temperature, Humidity and Differential
  • Integrated Buzzer for Alarm limits violation with acknowledgment facility.
  • Software calibration facility.
  • Password protected programming.
  • Isolated RS-485 communication with Modbus RTU Protocol.

Technical Specification

Input
  • Temperature & Humidity Sensor: Integrated
  • Differential Pressure Sensor: Integrated Differential Pressure Pressure sensor with Brass Hose Nozzles (Chrome Plated) for +Ve & -Ve Pressure connection
Range & Resolution
  • Temperature: -20.0 C to 60.0 C
  • Humidity: 0% to 100% RH,
  • Display resolution: 1 for Temperature and RH
Accuracy
  • Temperature: +- 1C
  • Humidity: +- 3 % RH
  • Differential Pressure: +- 1% of F.S.
Environmental
  • Operating Ambient Temp. : 0 to 50 C
  • Humidity: Below 95% RH, Non condensing.
Electrical
  • Supply voltage: 24VDC +-10%
  • Power consumption: Less than 1.2 watt at 24VDC
Indication
  • Differential Pressure: Upper 4-digit Seven Segment 0.4” Red L.E.D. display
  • Temperature: Middle 4-digit Seven Segments 0.4” Red L.E.D. display
  • Humidity: Lower 4-digit Seven Segment 0.4” Red L.E.D. display
  • Status indication: 3 L.E.D.s for Alarms, one for each parameter
  • Audio Indication: Integrated Buzzer for Alarm limits violation of any of the 3 parameters
Communication
  • RS-485 Slave: Isolated RS-485 communication with Modbus RTU Protocol
  • Programmable Settings: Baud rate (9600 bps), Parity (O/E/N), Data bits (8), Stop bits (1/2)
  • No of salve ID: 1-250
  • Minimum Polling Interval: 500 milliseconds
Programmable Parameters
  • Set point: Programmable as per input selection
  • Programming of parameters: 3 Nos. push button front keys (with password protection)
  • Alarm logic: High or Low, user programmable
Dimension
  • Flush mounting plate: SS-304
  • Front plate size: 90 mm (H) x 110 mm (W)
  • Back enclosure: MS with powder coated
  • Overall Dimension: 90mm (H) x 110 mm (W) x 43mm (D)
  • Mounting: Modular wall mounting with Stainless Steel Front
Applications of Clean Room Monitor with integrated sensor (CRM-313-I)
  • Clean room application in Pharmaceutical
  • Pharma Environments monitoring applications
  • HVAC (Heating, ventilation, Air conditioning, Cooling).
  • Animal house clean room
  • Cold Storage
Resources



Extra Information

Brand:
Ambetronics Engineers Pvt. Ltd.
